Adafruit Mini Thermal Printer Arduino


About

  1. Embedded Arduino Thermal Printer
  2. (TTL 5-9V) Support Raspberry Pi, Arduino, Beaglebone Black, Am335X, Imx6 Board, Linux/Android Driver.

 6,200

Compare

Arduino Serial Thermal Printer Description:

This is an embedded mini Thermal printer, Adafruit Mini Thermal Printer Serial Communication Can Attach with any Microcontroller Also can use as receipt printer, Use With Arduino also which is widely used in various occasions, such as supermarkets, convenience stores, post office, bank and so on. It is not a normal consumer product, but similar to consumer products. The compact size makes it easy to be embedded to any kinds of instruments and meters. With a nice appearance, you can even put it on the table. On the hardware side, we specially choose the TTL interface so that it can be directly controlled by development boards such as Arduino or Raspberry Pi. In the Internet of things era, it’s time to print out your ideas!.

A thermal printer typically contains at least these components:

  • Thermal head: Produces heat to create an image on the paper
  • Platen: A rubber roller which moves the paper
  • Spring: Applies pressure to hold the paper and printhead together
Thermal print head at high magnification.

Thermal paper is impregnated with a solid-state mixture of a dye and a suitable matrix, for example, a fluoran leuco dye and an octadecylphosphonic acid.

When the matrix is heated above its melting point, the dye reacts with the acid, shifts to its colored form, and the changed form is then conserved in metastable state when the matrix solidifies back quickly enough, a process

Arduino Serial Thermal Printer Serial Communication Adafruit



Arduino Serial Thermal Printer Features:

Low-noise direct thermal printing method
Printer control panel built-in GB18030 Chinese character
Fast printing speed
Can support Max. 39mm paper roll, the biggest paper roll of the same models
TTL interface
Rich of graphics/curves/characters print function
Easy paper loading structure
Support 5V-9V wide power voltage for Thermal printer

Printing method: Mini Thermal direct line printing
Paper loading method: easy paper loading
Paper width: 57mm Print width: 48mm
Resolution ration: 8dots/mm(384dots/line)
Life of printing head: 50km
Printing speed: 60mm/sec.; Max.80mm/sec.(voltage 8.5V)
Character size: 12x24dots, 24x24dots
Chinese character fonts: GB18030,12x24dots, 24x24dots
Outline dimensions: 111mmx65mmx57mm
Installation dimensions: 103mmx57mm
Embedded depth: 50mm
Paper roll specifications: width 57mm, Max. diameter 39mm

     Usage of Power and installation:

Interface: RS232
Input power: DC 12V
Operating temperature: 5~50
Storage temperature: -20~60
Operating humidity: 10%~80%
Storage humidity: 10%~90%

PACKAGE:

20 Centimeters * 14 Centimeters * 4 Centimeters

0.500 Kilogram

With Data cable and Power cable
Paper Roll one piece Include 57mm size
