W2809 Digital Temperature Control

W2809 Digital Temperature ControlAbout this item

• Temperature measurement range:-50Celsius-110Celsius
• Temperature 0.1,other paragraph 1 Celsius
• Accuracy:0.1Celsius
• The input voltage:DC12V
• Size:48mm(length) x 29mm(width) x 32mm
• Package includes:
  1 x Temperature Controller
  1 x Temperature Sensor

Temperature measurement range:-50℃～110℃ Temperature 0.1℃,other paragraph 1℃ Accuracy:0.1℃

• Return difference accuracy:0.1℃ Refresh rate:0.5s High temperature protection:0-110℃ The input voltage:DC12V
• Measurement input: NTC (10K 0.5%) waterproof type sensor Output:10 a relay all the way Environmental requirements:-10℃,-60℃ humidity 20%-85% Size:48mm(length) x 29mm(width) x 32mm Hole size:46 x 26.5mm W1209WK temperature Controller also named as a W2809 temperature controller. It is a very useful product for egg incubators. It also contains a waterproof temperature sensor prob. We can also use it as thermostats and other temperature control applications.W2809 Digital Temperature Control is very reasonable. this product is available at Mekatroniks
• en.wikipedia.org
  • Temperature controller monitoring instrument, show the measured temperature (red) and set temperature (blue) at the same time.
  • ❃❃ Programmable heating/cooling mode, delay start, high temperature alarm, Celsius/Fahrenheit mode, etc. (Note: The C/F button allows you to switch between Celsius and Fahrenheit temperatures.).
  • ❃❃ Measurement Range: -50 to 110 Celsius (-58 to 230 F), Control Precision: 0.1 .
  • ❃❃ Operating Voltage: DC12V 200mA. With a waterproof NTC (10K 0.5%) temperature sensor probe.
  • ❃❃ Can be widely used for fish tank water temperature control, incubation field, equipment cabinet, air conditioning system, temperature control protection, control cabinet cooling system and other DIY temperature control systems.

•









  ​Temperature measurement range:-50Celsius-110Celsius
  Temperature 0.1,other paragraph 1 Celsius
  Accuracy:0.1Celsius
  Return difference accuracy:0.1Celsius
  Refresh rate:0.5s
  High temperature protection:0-110Celsius
  The input voltage:DC12V
  Measurement input:NTC (10K 0.5%) waterproof type sensor
  Output:10 a relay all the way
  Environmental requirements:-10Celsius,-60Celsius humidity 20%-85%
  Size:48mm(length) x 29mm(width) x 32mm
  Hole size:46 x 26.5mm
