XH-M603 Battery Charging Controller

The XH-M603 Battery Charging Controller adds voltage-based switching to a compatible battery charging setup. You can configure a lower threshold to begin charging and an upper threshold to disconnect the charging source.

Its digital display and adjustment buttons provide a convenient interface for setup. For students, technicians, and electronics builders in Pakistan, it offers a practical component for exploring automatic charging control.

Adjustable Start and Stop Settings

Separate start and stop settings let the controller respond to changes in battery voltage. Choose both values according to the battery manufacturer’s requirements and the charging system’s design.

Before using a setting in a project, verify the displayed voltage against a suitable meter. Check switching behaviour through a complete test cycle with the intended charger and battery.

Requires a Suitable Battery Charger

This board controls the charging connection. It does not provide a complete charging profile or current limiting, so the external charger must supply the correct regulated voltage and current.

For multi-cell lithium packs, retain the appropriate battery management and balancing system. A pack-voltage switching board does not replace individual cell protection.

Plan Your Installation

Check the actual board’s terminal markings and wiring diagram before making connections. Select wire sizes, connectors, and circuit protection appropriate for the charging current.

Also allow space for the display, adjustment buttons, and mounting points. An enclosure can help keep the board secured and prevent accidental contact with its connections.

Typical Applications

• Compatible battery-charging control projects.
• Adjustable charging cutoff experiments.
• Educational voltage-monitoring demonstrations.
• Custom charging panels.
• Workshop electronics prototypes.

Product Specifications

Buy XH-M603 Battery Charging Controller in Pakistan

Choose the XH-M603 Battery Charging Controller from Mekatroniks for compatible voltage-controlled charging projects. Match the board, charger, battery, and wiring ratings before installation.
